G 1010 Greka

G 1010 Greka

Suitable for use in buildings where continuous polycarbonate skylight installation is required. The fact that the lateral binned form is compatible with each other provides an easy and fast installation.

  • It has a high bearing capacity due to its trapezoidal structure.
  • It can be applied on roofs where the roof slope is more than 7%.
  • It has high heat resistance.
  • It shows high impact resistance.
  • It is produced transparent or opal according to the appropriate light requirement.
  • Produced in desired length depending on architectural needs and transportation conditions.
  • Can be bent in vault roof etc. applications.
  • It has high UV resistance.

G 1010 Greka

Suitable for use in buildings where continuous polycarbonate skylight installation is required. The fact that the lateral binned form is compatible with each other provides an easy and fast installation.

  • It has a high bearing capacity due to its trapezoidal structure.
  • It can be applied on roofs where the roof slope is more than 7%.
  • It has high heat resistance.
  • It shows high impact resistance.
  • It is produced transparent or opal according to the appropriate light requirement.
  • Produced in desired length depending on architectural needs and transportation conditions.
  • Can be bent in vault roof etc. applications.
  • It has high UV resistance.

Technical Specifications

Technical Specifications Value
Thickness 12 mm
Useful Width 1010 mm
Panel Gap for Installation 1010 mm
Length Min 100 mm, Max. Depending on Transport and Installation Conditions
Thermal Conductivity Coefficient 2.30 W/m²K
Thermal Expansion Coefficient 0.065 mm/m°C
Light Transmittance Clear %72, Opal %55
Temperature Resistance -40 °C / +120 °C

Technical Specifications

Technical Specifications Value
Thickness 12 mm
Useful Width 1010 mm
Panel Gap for Installation 1010 mm
Length Min 100 mm, Max. Depending on Transport and Installation Conditions
Thermal Conductivity Coefficient 2.30 W/m²K
Thermal Expansion Coefficient 0.065 mm/m°C
Light Transmittance Clear %72, Opal %55
Temperature Resistance -40 °C / +120 °C
